Alpha-420

Features
  • DELTA 420 Flexo printing press is a kind of printing equipment which is developed by our company on the basis of absorbing foreign advanced technology experience and combining with our core technology. The press is for shipping label, adhesive material, film and other materials. The whole machine adopts three servo synchronization control, uses LED UV curing, high precision and low pollution. This machine has advanced functions, simple operation, low production cost, and can be customized according tocustomer needs.

Unwind

Our unwind unit is controlled by a closed-loop tension system insuring a constant web tension that is also crucial throughout the press and includes a hydraulic lifting system,(It also has&hellip) an integrated dust removal unit and a corona treatment system.

waste rewind

This structure is easy to waste rewind and not easy to break. It has a good performance on waste rewind of irregular and very fine waste edges, reduces the waste of downtime caused by cutting waste edges and improves production efficiency.

Flexo unit

Reliable, precise and productive. This printing technology brings ease of use and stable printing. Using a patented printing pressure adjustment, it will deliver repeatability and high-quality printing.

Rail system for mounting

• Turn bar unit with an integrated lateral adjustment • Cold foil unit that can be moved to any print station • Lamination station

orizontal die cutting unit

This technology eliminates the problem of long die changeovers and slower matrix stripping speeds discharge, reducing the waste downtime caused by the broken edges and improving production efficiency.

Rewinder

Servo driven and with accurate tension control; they are smooth, reliable and capable of handling a wide range of substrates including delicate, perforated or punched products. Our rewinders can be tailored to meet individual needs and create a clear, competitive advantage for any business.



  • 產品性能及特點:

  • 從20um的薄膜到300克卡紙靈活轉換
  • 采用抽屜式結構,可快速更換刀輥,操作簡便。
  • 液壓式施壓,數顯壓力,穩定性高,便于記憶重復操作。(CLTS*)
  •

  • 模塊設計,可以加裝柔印色組,實現簡單印刷模切一體機。
  • 可以選購紙卷尾部不干膠貼標封口裝置。
  •
  •


Specification
Maximum paper width
430mm
Gearing
1/8”(3.175mm)
Maximum printing width
420mm
Motorization
Servomotor
Maximum unwind diameter
1000mm
Air-pressure
100PSI(7BAR)
Maximum rewind diameter
600mm/min
Lubrication
Automatic
Repeat printing
203~610mm
Material
Film, paper, label material
Repeat die cutting
279~610mm
Max mechanical speed
200m/min
